Device Specification

Model Number: TU-04-C04

System Feature

Connection is from device connected to server.
Once system power up, it will auto create a persistence connection to the server without user intervention.
Server can be placed either at public cloud, private cloud or LAN.
Device able to work behind firewall.

Based on Imping E710 chip with improved read rate and superior receive sensitivity for long rang reading.
Build in 1200 Tag Cache size for highspeed reading.
Able to match with various type of 50Ω Antenna to manage the tag detection range and angle.
Auto antenna detection and will only turn-on the antenna output channel if the antenna is detected.
User can also adjust the output power from 1dBm to 33dBm to manage the reading distance remotely though the server.
With the correct antenna and low lost feeder cable, the reading can achieve up to the reading range of 15meter.
Build in device core temperature sensor, providing remote temperature monitoring when the device is operating under high temperature environment.
Over temperature error auto stop and notification.
Build in Tag Selection Filter that only detect the tag that matches or NOT matches the selection criteria.
Auto read tag data on any one of the tag’s memories banks when the tag is detected.
Write/Lock/Kill Tag with Tag Selection Filter.

2 input port and 2 output port.
Able to configure the input port as I/O input or user push button input.
Push button input allow to auto user press action, single press, double press, triple press and long press (press and hold more than 4 second).
Provide number of input on/off cycle counter to prevent missing cycle.
Wet contact output design using MOSFET thus support up to 30V 1A output current without the wear and tear of the relay contact.
Output port can be configured as standard High/Low output or Auto Pulsed output.
Configurable pulse duration (configure separately for High level and Low-level period) and number of pulse cycle when trigger by server.

Auto connect with the Internet Time Server to fetch the Real time value (EPOC Time) when network is connected and internet link is available.
Manually set time by server if internet link is not available.
Auto readjust the time drift periodically.
Append the EPOC time to all the message.

Easily link up with the device without connecting to the network.
Suitable for direct connection with PC/Host system locate beside the device.
Just add an extra JSON layer of wrapper to wrap around the same JSON messaging standard used in the MQTT Broker Server communication.
Thus provide an easy path for future system expansion, from localized system architecture to network-based system architecture.

Open Standard protocol and readily available either using paid version or free version of MQTT Broker Server.
Messaging format based on JSON format.
JSON messaging format is supported by various programming language and easily integrated to any existing system.

A short distance (Up to 10 meter) communication bus.
Allow to attach external I/O Expansion Unit.
Maximum up to 8 unit of I/O Expansion Unit, thus providing up to 64unit of input port and 64unit of output port.

Item	Description
Input Voltage	DC 12V to 24V or POE
Supported POE	IEEE802.af/at, RJ45 Connector Power pin on 1&2, 3&6 and 4&5, 7&8.
System Power Consumption	15W Max
Operation Humidity	20%-90%RH
Operation Temperature	25°C to 45°C
Storage Humidity	10-95RH
Storage Temperature	0°C to 85°C
Enclosure Dimension	131mm (W) x 130mm (L) x 28mm (H) with 4x mounting screw hole
Enclosure Type	Aluminum Extrusions

Item	Description
Antenna Channel	4 Channel
Operation Frequency	919MHz~923MHz Auto Hopping (According to MCMC Class Assignment for RFID)
Output Power	33dBm Max, User Adjustable in 1dBm Step
UHF Tag Protocol	EPC global UHF Class 1 Gen 2 ISO 18000-6C

Item	Description
Frequency	2.4Ghz~2.5Ghz
Supported Wi-Fi Protocol	802.11 b/g/n
Antenna Type	External
Security Protocol	WPA/WPA2 personal, WPA/WPA2 Enterprise
Encryption Protocol	WEP/TKIP/AES

Item	Description
Speed	RJ45, 10/100 Mbps
Power over Ethernet	IEEE802.af/at, RJ45 Connector Power pin on 1&2, 3&6 and 4&5, 7&8.
Voltage	44V~57V DC

Item	Description
Supported Protocol	USB Virtual Comm Port
Baud	921600 Baud, 8bit, no-parity, 1 stop bit

Item	Description
Server Connection	MQTT Broker with TCP, TCP-TLS, Web-Socket Connection
Server Port	User Definable
Encryption/Security	Public CA, Self-Signed Certificate
Messaging Format	JSON
Other	NTP auto RTC update

Output Port Architecture

Item	Description
Input Port	2 Channel
Connection Type	N Type, External Sink to Ground to Trigger On
Max Sink Current	5mA

Input Port Architechture
